Hazardous-Location Emergency Lighting — Code Compliance Checklist (UL 924 • UL 844 • NEC 500–516)

Hazardous-location emergency lighting has two jobs: keep people oriented to exits and prevent your equipment from becoming an ignition source. This code compliance checklist walks facility managers and electrical contractors through the essentials—UL 924 vs UL 844, NEC 500–516 classification, NFPA 101 illumination targets, documentation for the AHJ, and recurring test logs—so you can pass inspections and stay safe.

Last updated: October 2025

Hazardous Emergency Lights Explosion‑Proof Combo Buyer’s Guide (Pillar)

Educational Guide UL 924 • UL 844 • NFPA 101 • OSHA For Facility Managers & Electrical Contractors

1) Know Your Classified Area (Class / Division / Group / T‑Code / Ta)

  • Class: I (gases/vapors), II (dust), III (fibers).
  • Division: Div 1 = hazard present under normal conditions; Div 2 = abnormal/occasional.
  • Group: Gas/dust family (e.g., IIA/IIB/IIC; E/F/G) that matches your process.
  • T‑Code: Maximum surface temperature the fixture can reach—must be below the ignition temp of your atmosphere.
  • Ambient (Ta): T‑codes apply at a stated ambient (e.g., “T4 at Ta 40 °C”). Ensure the device’s rating covers your hottest conditions.

Tip: Keep a one‑page classification map from your design team. AHJs often ask for it during plan review and field inspection.

Background primer: Class, Division & Group — Plain-English Primer

2) Product Listings That Must Appear (UL 924 + UL 844)

  • UL 924 (Emergency Lighting): Verifies transfer to battery and ~90‑minute emergency runtime for egress.
  • UL 844 (Hazardous Location): Verifies construction for the exact Class/Division/Group and T‑Code (or max surface °C for dust).
  • Nameplate: The fixture’s label should show Class/Div/Group, T‑Code, and Ta range. Photograph labels for your submittal file.

Related: T‑Codes for Explosion‑Proof Egress Fixtures

3) Enclosure & Environment (NEMA / IP, Corrosion, Cold)

  • NEMA/IP: Use NEMA 4X or IP66+ where washdown, rain, or salt spray are present. (This is in addition to UL 844.)
  • Corrosion: Consider marine‑grade coatings or fiberglass/aluminum alloys in chemical or coastal sites.
  • Cold: For freezers/outdoors, specify cold‑weather battery heaters to preserve runtime.

Compare terms: Explosion‑Proof vs Wet‑Location vs Outdoor

4) Installation & Wiring (NEC 500–516 Essentials)

  • Conduit & Seals: Use the correct sealing fittings and thread engagement per the hazardous location rating; observe compound cure times.
  • Boxes & Hubs: Only listed explosion‑proof boxes/hubs; don’t mix ordinary fittings in classified runs.
  • Mounting: Follow torque specs on enclosure bolts (even, cross‑pattern); keep flame paths clean and undamaged.
  • Circuits: Clearly identify emergency circuits; document transfer devices; label panels/J‑boxes (“EM”).

How‑to: Installing Explosion‑Proof Emergency Lighting

5) Illumination & Placement (Egress Performance)

  • Coverage: Position heads to achieve code‑acceptable egress illumination (check your AHJ’s foot‑candle criteria and uniformity).
  • Aiming: Use adjustable heads; verify paths, stairs, and doors are lit during the 90‑minute test.
  • Combos vs Separate: Combos above doors; separate hazardous‑location emergency lights for wide areas/high bays.

Always verify local AHJ requirements for minimum/average illumination and any site‑specific exceptions.

6) Commissioning Docs for the AHJ

  • Cut Sheets: UL 924 and UL 844 listings called out; mark the exact options ordered.
  • Nameplate Photos: Show Class/Div/Group, T‑Code, and Ta on installed devices.
  • As‑Builts: Identify classified zones and emergency circuits on drawings; note sealing fitting locations.
  • Test Forms: Completed 30‑second and 90‑minute logs (see next section).

Inspection prep: What Inspectors Check

7) Recurring Tests & Logs (Monthly / Annual)

  • Monthly: 30‑second functional test (push‑to‑test or self‑diagnostics) and visual inspection (gaskets, corrosion, lenses).
  • Annually: Full 90‑minute discharge; confirm illumination along paths for entire test window; re‑aim heads if required.
  • Recordkeeping: Keep pass/fail logs with corrective actions; AHJs routinely ask for these.
  • Self‑Test: If available, enable and document indicators/status codes to reduce labor.

8) Common Causes of Inspection Failure

  • Fixtures listed to UL 924 but not UL 844 for the specific Class/Div/Group.
  • Wrong T‑Code or insufficient Ta rating for process/ambient conditions.
  • Ordinary‑location fittings used in classified conduit runs; missing seals.
  • Insufficient illumination at floor (aiming/spacing not verified during 90‑minute test).
  • Missing test logs or unlabeled emergency circuits.

9) Printable Quick Checklist

  • Classified area map: Class/Div/Group, T‑Code, and Ta confirmed
  • Fixtures labeled UL 924 and UL 844 (matching nameplate)
  • NEMA/IP rating matches environment (washdown, outdoor, corrosion)
  • NEC‑compliant fittings, seals, boxes; torque per spec
  • 90‑minute illumination verified; heads aimed; doors/stairs covered
  • Commissioning packet: cut sheets, nameplate photos, as‑builts, seal locations
  • Test logs: monthly 30‑sec + annual 90‑min; corrective actions recorded

This guide is informational and not a substitute for professional engineering judgment or the authority of your AHJ.
