Class I Div 1 vs Div 2 comes up anytime you’re specifying emergency lights or EXIT signs in gas/vapor areas. This guide breaks down where each division applies, what listings you need (UL 844 & UL 924), how T-codes and ambient (Ta) affect selection, and the wiring/inspection details contractors and facility teams must get right.
Last updated: October 2025
At a Glance: Div 1 vs Div 2
- Division 1: Hazard (flammable gas/vapor) is present under normal operation—equipment must contain and cool internal ignition.
- Division 2: Hazard is present only abnormally/occasionally—equipment still must not ignite a leak or upset condition.
Code context: Hazardous-Location Code Checklist
Where Each Applies (Common Areas)
- Div 1 examples: Spray booths, solvent mixing rooms, digester headspaces, pump skids handling live vapors.
- Div 2 examples: Adjacent storage rooms, transfer corridors, areas near process equipment where leaks are abnormal.
Listings You Need (UL 844 + UL 924)
- UL 844: Hazardous-location listing; nameplate must show Class I, Division (1 or 2), Group (IIA/IIB/IIC), and often ambient limits.
- UL 924: For emergency egress devices (lights/EXIT signs): transfer to battery and ~90-minute runtime.
Temperature ratings: T-Codes for Explosion-Proof Fixtures
T-Codes & Ambient (Ta)
- T-code: Maximum surface temperature the device can reach; must be below the auto-ignition temperature of the gas/vapor.
- Ambient (Ta): T-code applies at a stated ambient—hotter spaces may require a different model or rating.
- Groups: IIA, IIB, IIC matter—IIC (e.g., hydrogen) is most stringent.
Equipment Implications (Construction & Enclosures)
- Div 1 fixtures typically use heavier explosion-proof housings and flame paths to contain ignition in normal operation.
- Div 2 fixtures are designed to prevent ignition during abnormal conditions (leaks); construction can be lighter but still sealed/gasketed.
- NEMA/IP: Add NEMA 4X/IP66 for washdown/corrosion—this is in addition to the hazardous-location listing.
Compare terms: Explosion-Proof vs Wet-Location vs Outdoor
Installation & Wiring (Seals, Hubs, NEC)
- Sealing fittings: Use listed explosion-proof seals/compounds at required distances; no ordinary hubs in classified runs.
- Flame paths: Keep mating surfaces pristine; torque cover bolts to spec; re-check after service.
- Labeling: Identify emergency circuits; keep cut sheets and nameplate photos for the AHJ.
Placement & Photometrics
- Combos vs separate: Combos above doors; add hazardous-location lights to cover large or obstructed areas.
- Aiming & testing: Verify foot-candles at floor for the full 90 minutes; re-aim as needed.
Decision Flow & Cost Considerations
- Identify zone: Is it Div 1 (normal presence) or Div 2 (abnormal)?
- Confirm Group & T-code: Match gas family and temperature rating; check ambient (Ta).
- Pick form factor: Combo at doors; separate lights for wide/high-bay coverage; consider remote heads if power is outside the zone.
- Budget: Div 1 gear is typically higher cost/heavier; Div 2 can reduce unit cost but must still meet UL 844 and UL 924.
- Docs: Assemble cut sheets, nameplate photos, and test forms before the walk-through.
Inspection prep: What Inspectors Check
Quick Comparison Table
| Criteria | Div 1 | Div 2 |
|---|---|---|
| Hazard likelihood | Present under normal operation | Present only abnormally/occasionally |
| Construction | Heavier explosion-proof housings | Ignition-safe under abnormal leaks |
| Typical areas | Spray booths, digester headspace | Adjacent storage/transfer zones |
| Cost/weight | Higher | Lower (model dependent) |
Quick FAQ
Can a Div 2 fixture be used in a Div 1 area?
No. Div 1 requires listings specifically for Div 1 (or equivalent Zone rating); always match the nameplate to the area classification.
Do I still need UL 924?
Yes—if the device is an emergency light or EXIT sign. UL 844 handles ignition safety; UL 924 handles egress performance.
Is NEMA 4X enough outdoors?
No. NEMA/IP ratings are for environment (water/corrosion). In classified areas, you also need the correct UL 844 Class/Division/Group.
Printable Selection Checklist
- Identify Div 1 vs Div 2; confirm Group (IIA/IIB/IIC)
- Select T-code with margin; verify Ta on the nameplate
- Verify UL 844 + UL 924 on the exact model/options
- Plan photometrics (combos at doors, fills for large areas)
- Prepare cut sheets, nameplate photos, and test logs for AHJ
This guide is informational and not a substitute for professional engineering judgment or the authority of your AHJ.
