Raised-Letters 100-Ft Photoluminescent Exit Sign (Non-Electrical)

SKU: EG100-1-R
$210.97

Got questions?

Give us a call 800-847-1955!

Raised-Letters 100-ft Photoluminescent Exit Sign — No Power Required

The EG100 EXI-GLOW is a raised-letters 100-ft photoluminescent exit sign that provides code-compliant, non-electrical egress guidance. It installs without wiring or batteries and is ideal for schools, healthcare, retail, and commercial interiors. Explore more in our photoluminescent exit signs collection or pair with a low-profile exit sign.

UL 924 100-ft Viewing No Power Zero Energy Cost Non-Radioactive Indoor Use

Key Features

  • Power-free operation: no wiring, batteries, or bulbs—zero energy cost.
  • 100 ft legibility with high-contrast raised letters for blackout conditions.
  • Field-selectable chevrons included for fast arrow configuration.
  • Non-toxic, non-radioactive photoluminescent substrate.
  • Hazard considerations: non-electrical signage is typically acceptable in explosion-risk areas; final acceptance in classified locations is at the AHJ’s discretion (this is not UL 844 electrical equipment). Listed for floor-proximity installation.
  • Long service life: 25+ year life expectancy with minimal maintenance.

Spec Sheet

Download EG100 Photoluminescent Exit Sign Spec Sheet (PDF)

Illumination

  • Photoluminescent after-glow legend, visible up to 100 ft.
  • Requires continuous ambient illumination of ≥ 5 foot-candles (54 lux) on the sign face during occupancy for full charge.
  • Charges from typical LED, fluorescent, or HID general lighting.

Electrical

  • N/A — non-electrical device. No AC input, charger, or battery.
  • Zero energy consumption; no test switches or status LEDs.

Mounting

  • Surface, flag (90°), or ceiling/stem mount; mounting hardware included.
  • Approved for standard or floor-proximity (low-level) placement.
  • Mechanical-only install; no wiring or conduit. Use included hardware and verify any anchoring/placement with the AHJ.

Housing / Finish

  • Durable ABS frame with raised photoluminescent letters.
  • Frame colors: black, green, or red.

Options

  • Single- or double-face configurations.
  • Field-applied directional chevrons (left, right, both, or none) included.

Warranty / Listings

  • UL 924 photoluminescent exit (meets 2015 IBC); compliant with NFPA 101 and OSHA.
  • Approvals: ICC ES 6040, CA SFM #6200-1617-100, LA RR 25531.
  • Operating temperature: -20 °F to 150 °F (-29 °C to 66 C); interior use only.
  • Buy American Act (BAA) & Build America, Buy America (BABA) compliant.
  • Warranty: 1-year limited (materials & workmanship).

Dimensions

  • Letter height: 7 in • Stroke: 0.875 in.
  • Overall: 15.875 in W × 8.625 in H × 0.375 in D.

Ordering

  • EG100-1-B — single face, black frame
  • EG100-2-G — double-face, green frame
  • EG100-1-R — single face, red frame

FAQs About EG100 (100-ft Photoluminescent)

What makes the EG100 different from standard 100-ft PL signs?

EG100 combines a raised-letter legend, broad plan-review approvals (ICC ES 6040, CA SFM, LA RR), and BAA/BABA compliance in an interior-only package. It’s designed for long interior sightlines where non-electrical signage is preferred.

Can I use EG100 in hazardous (classified) locations?

Because EG100 is non-electrical, it is typically acceptable where electrical ignition sources are restricted. However, it is not UL 844 explosion-proof equipment. Final acceptance for classified areas is determined by your AHJ; submit the spec sheet and listings for review.

When should I specify floor-proximity EG100 units?

Low-level placement can aid wayfinding when smoke lifts the hot layer above head height. Use EG100 at high-location and floor-proximity to bracket the path where codes or your life-safety plan call for redundant marking.

What documentation should I include for plan review?

Provide the UL 924 listing page, ICC ES 6040 evaluation report, CA SFM and LA RR listings, the spec sheet, and a note that the face receives ≥ 5 fc (54 lux) during occupancy at the installed height.

How do temperature extremes affect performance?

EG100 is rated from -20 °F to 150 °F. Charging may occur more slowly near the low end of the range; ensure egress lighting delivers the target face illuminance during occupancy. Do not use outdoors or in wet areas—choose a wet-location model instead.

Can I mount EG100 with adhesive only?

No. Use the mechanical mounting hardware provided (surface, flag, or ceiling/stem). Adhesives alone can creep over time and do not provide compliant anchorage for life-safety signage.

Is EG100 suitable where strong disinfectants are used (healthcare/food)?

Yes—clean with a soft cloth and mild soap. Avoid abrasives, ammonia, oxidizers, or solvent-based cleaners that can haze the luminous surface or frame finish.

Can EG100 be paired with luminous egress path markings?

Yes. EG100 identifies exits while photoluminescent path-marking products define stairs, handrails, and pathways. Specify both where required by project scope or AHJ guidance.

Are there jurisdictional preferences for red vs. green legends?

Some AHJs specify a legend color; others allow either. EG100 offers red or green—choose the color that meets local rules and maximizes contrast with adjacent finishes.

What should I retain for the inspector after installation?

Keep the product label visible, retain the UL 924 and evaluation listings with the spec sheet, record sign locations/face configuration, and note initial face-illuminance readings for the commissioning file.
