LED Area Light – 140W Max, Outdoor Selectable Wattage

LED Outdoor Area Light – 140W Max, Selectable Wattage Fixture

This LED outdoor area light delivers reliable high-lumen performance with selectable output between 60W, 90W, 120W, and 140W. Designed for parking lots, campuses, and commercial exteriors, it produces up to 23,000 lumens with precision Type II–V optics. This LED high output area light is DLC Premium qualified, dark-sky compliant, and built to withstand demanding outdoor environments.

• Selectable: 60W / 90W / 120W / 140W
• Up to 23,000 Lumens
• IP65 Rated for Outdoor Use
• DLC Premium & IDA Compliant

Download LED Area Light Spec Sheet (PDF)

Performance

• Selectable wattages: 60W, 90W, 120W, 140W
• Lumen range: 9,600 – 23,000 lumens
• Efficacy: Up to 172 lumens per watt
• Color Temperature: 3000K / 4000K / 5000K switchable
• Optics: Type II, III, IV, and V distributions

Construction

• Die-cast aluminum housing with integrated heat sink fins
• Powder-coated bronze finish with stainless steel hardware
• Hinged driver access door with 12" whip included
• Includes pole arm for 4" or 5" square/round poles

Electrical

• 120–277VAC input standard (277–480VAC optional)
• Class 2 power supply with 0–10V dimming
• Surge protection: 10kA or 20kA depending on voltage
• Power factor = 0.90, THD < 20%

Mounting Options

• Includes standard straight arm mount
• Optional: slipfitter, trunnion, swivel, wall mount, and tenon adaptors

Listings & Certifications

• UL Listed for wet locations (IP65)
• DLC Premium Qualified
• IDA dark-sky compliant with 3000K lock module (RXAR-DSFA)

Warranty

• 5-year standard warranty
• Optional 10-year extended warranty available

Frequently Asked Questions

How many lumens does this LED area light produce?

It delivers between 9,600 and 23,000 lumens depending on the wattage setting you select—ideal for high-output commercial applications.

What are the selectable wattage options?

You can switch between 60W, 90W, 120W, and 140W directly from the fixture via dip switches—no rewiring or drivers needed.

Is this a dark sky compliant area light?

Yes. It offers zero uplight and can be locked to 3000K to meet IDA standards using the RXAR-DSFA module.

Is it suitable for LED outdoor area lighting?

Absolutely. It’s IP65 rated and engineered for rugged outdoor use in all weather, with efficient heat dissipation and corrosion resistance.

Can I install this on a round pole?

Yes. It includes a straight arm compatible with both 4" and 5" round or square poles, and supports additional mounts like slipfitters or trunnions.
