LED Area Light – 250W Max, Outdoor Selectable Wattage

LED Outdoor Area Light – 250W Max, Field-Adjustable Wattage

This LED outdoor area light delivers powerful, high-lumen performance with selectable output between 100W, 150W, 200W, and 250W. With up to 38,000 lumens and multiple distribution types, it’s ideal for large-scale exterior lighting applications like parking lots, campuses, and roadways. Built for durability, this LED high output area light features dark-sky optics, DLC Premium certification, and rugged IP65 construction.

• Selectable: 100W / 150W / 200W / 250W
• Up to 38,000 Lumens
• IP65 Rated for Outdoor Use
• DLC Premium & IDA Compliant

Download LED Area Light Spec Sheet (PDF)

Performance

• Selectable wattages: 100W, 150W, 200W, 250W
• Lumen range: 14,500 – 38,000 lumens
• Efficacy: Up to 161 lumens per watt
• Color Temperature: 3000K / 4000K / 5000K switchable
• Optics: Type II, III, IV, and V light distribution

Construction

• Die-cast aluminum housing with stainless steel hardware
• Powder-coated finish and integral heat sink fins
• Hinged driver access door with included 12” whip
• Standard pole arm fits 4" or 5" round or square poles

Electrical

• 120–277VAC input standard (277–480VAC available)
• 0–10V dimming driver included
• Surge protection: 10kA (standard), 20kA (optional)
• Power factor = 0.90; THD < 20%

Mounting Options

• Standard pole arm included
• Optional mounts: slipfitter, trunnion, swivel, wall bracket, tenon adaptors

Listings & Certifications

• UL Listed for Wet Locations (IP65)
• DLC Premium Qualified
• IDA Dark Sky Compliant (with 3000K lock module)

Warranty

• 5-year standard warranty
• Optional 10-year extended warranty available

Frequently Asked Questions

How many lumens does this LED area light produce?

Depending on the selected wattage, it delivers between 14,500 and 38,000 lumens—ideal for large-scale outdoor lighting applications.

Can I change wattage and color temperature in the field?

Yes. This model includes internal dip switches for easy in-field selection between 100W–250W and 3000K–5000K without rewiring.

Is it compliant with dark-sky regulations?

Yes. It offers zero uplight and can be configured for 3000K color to meet IDA guidelines using the RXAR-DSFA accessory.

Is this fixture suitable for high-mount applications?

Absolutely. With up to 38,000 lumens and multiple beam distributions, it’s excellent for parking lots, pole-mounted roadway lights, and security lighting.

What are the input voltage options?

120–277VAC input is standard, and 277–480VAC options are available for industrial and municipal applications.
