LED Area Light – 300W Max, Outdoor Selectable Wattage

LED Outdoor Area Light – 300W Max, Field-Selectable Wattage

This LED outdoor area light is engineered for high-performance commercial lighting applications with selectable wattages of 120W, 180W, 240W, and 300W. Capable of producing up to 46,000 lumens, it’s ideal for large outdoor spaces such as parking lots, roadways, industrial sites, and campuses. Designed for maximum versatility, this LED high output area light is DLC Premium listed, IP65 rated, and fully dark-sky compliant when configured to 3000K.

• Selectable: 120W / 180W / 240W / 300W
• Up to 46,000 Lumens
• IP65 Rated for Outdoor Use
• DLC Premium & IDA Compliant

Download LED Area Light Spec Sheet (PDF)

Performance

• Selectable wattages: 120W, 180W, 240W, 300W
• Lumen output: 18,000 – 46,000 lumens
• Efficacy: Up to 169 lumens per watt
• Selectable CCT: 3000K / 4000K / 5000K
• Distributions: Type II, III, IV, V

Construction

• Rugged die-cast aluminum housing with integrated heat sink fins
• Powder-coated finish with stainless steel hardware
• Hinged driver access door with 12” whip included
• Includes pole arm for 4" or 5" square or round poles

Electrical

• 120–277VAC input standard (277–480VAC optional)
• 0–10V dimming driver included
• Surge protection: 10kA (standard), 20kA (optional)
• Power factor = 0.90; THD < 20%

Mounting Options

• Standard pole mount arm included
• Optional: slipfitter, trunnion, swivel, wall bracket, and tenon adaptors

Listings & Certifications

• UL Listed for wet locations (IP65)
• DLC Premium Qualified
• IDA compliant when CCT is locked to 3000K with RXAR-DSFA module

Warranty

• 5-year standard warranty
• 10-year extended warranty available upon request

Frequently Asked Questions

How many lumens does this LED area light produce?

This model produces up to 46,000 lumens at 300W and as low as 18,000 lumens at 120W, giving you full flexibility based on application needs.

What is the benefit of selectable wattage and CCT?

You can fine-tune light output and color temperature on-site using built-in dip switches—choose from 120W to 300W and 3000K, 4000K, or 5000K.

Where should I use this LED area light?

This LED high output area light is perfect for parking lots, industrial zones, loading docks, and large exterior spaces that require reliable visibility.

Is this fixture compliant with dark sky regulations?

Yes. When locked to 3000K with the optional RXAR-DSFA module and installed in a full cutoff orientation, it is IDA compliant.

Can this fixture operate at high voltage?

Yes. In addition to 120–277V, this fixture can be ordered with a dedicated 277–480V driver and enhanced surge protection.

Product Features

• Brand: TraceLite
• Outdoor Area Lights
• Product: RXAR-300
• Outdoor Lighting
