Recessed Square LED Emergency Light — Dual 1 W Heads, 10 W Remote Capacity, 6 V SLA 90 min, 120/277 V — Features & Specs
The LEDR-7 recessed square LED emergency light installs flush in drywall or T-bar ceilings for clean, architectural egress lighting. Dual 1 W LED heads, a sealed 6 V SLA battery for 90 minutes of runtime, and a built-in 10 W remote-capacity driver make it a compact host for additional remote heads. Explore more recessed emergency lighting and compatible emergency lighting remote heads.
Key Features
- UL 924 listed; dry-location rated.
- Recessed, flush-mount square trim; steel back-box with adjustable bar hangers.
- Dual 1 W LED heads with chrome reflectors and clear lenses.
- Built-in 10 W remote capacity for compatible 6 V remote heads.
- Universal 120/277 VAC input with status LED & push-to-test.
- 6 V SLA battery; 90-minute runtime; solid-state transfer; two-rate charger (~24 h).
- 20-gauge steel trim plate — white (standard) or black (optional); spring-clip retention.
- Compliance: NFPA 101, NEC, OSHA.
LEDR-7 recessed square LED emergency light — labeled overview sketch
Related Recessed Emergency Lighting Guides
Spec Sheet
Download Emergency Unit Spec Sheet (PDF)
Illumination
- Two 1 W LED heads with chrome reflectors and clear lenses.
Electrical
- 120/277 VAC universal input with bi-color status LED and push-to-test switch.
- 6 V sealed lead-acid battery; minimum 90-minute operation.
- 10 W remote-capacity driver powers compatible 6 V remote heads (e.g., MR16 6 V LED types).
- Automatic solid-state transfer; two-rate charger (~24 h full recharge).
- Input load: 5.0 W | Input current: 0.05 A @ 120 V • 0.03 A @ 277 V.
Mounting
- Recessed steel back-box with adjustable bar hangers (included).
- Trim springs secure flush installation in drywall or T-bar grid ceilings.
Housing / Trim
- 20-gauge steel trim plate — white (standard) or optional black.
Options
- SDT — self-diagnostic testing (monthly, biannual, annual).
Warranty / Listings
- 5-year warranty on electronics and housing; battery prorated 2 years.
- UL 924 listed for dry locations (25 °C); compliant with NFPA 101, NEC, OSHA.
Dimensions
- Trim plate: 13 ¼" L × 9 ¼" W
- Depth above ceiling: 8 ½"
Recessed LED Emergency Lights — Trim, Remote Capacity & Cutout
Models below are from our recessed LED emergency lights . Compare trim shape, remote capacity, battery class, and ceiling interface to pick the right host.
| Model / Link | Trim Shape | Remote Capacity | Battery / Runtime | Ceiling Interface | Cutout / Box | Best Use |
|---|---|---|---|---|---|---|
| This model — recessed square LED emergency light — 10 W RC | Square trim; dual 1 W heads | 10 W @ 6 V | 6 V SLA · 90 min | Drywall / T-bar; bar hangers | See spec (13¼"×9¼" trim; 8½" depth) | Flush look + drives 6 V remote heads |
| recessed round downlight emergency unit | Round gimbal downlight | 0–20 W (model dependent) | Ni-Cd / SLA · 90 min | Drywall / T-bar; brackets/hangers | See spec sheet | Pinpoint beams; minimal aperture |
| architectural recessed emergency light — micro heads | Micro dual heads (slot) | 0–10 W (model dependent) | Ni-Cd · 90 min | Drywall reveal; spring retention | See spec sheet | Galleries, amenity ceilings |
| recessed emergency light — grid-ceiling ready | Square trim; grid-ready | 0–10 W (model dependent) | Ni-Cd / SLA · 90 min | T-bar grid compatibility | See spec sheet | Suspended ceiling retrofits |
Sizing tip: add host head watts + remote head watts and verify the battery supports a full 90-minute UL 924 duration; match 6 V remote heads to the host’s RC output.
