Wet-Location LED Emergency Light – Dual 1 W Heads, Vandal-Resistant Design, 18 ft Spacing — Features & Specs
The LEM54-N4 wet-location thermoplastic LED emergency light delivers dependable, code-compliant egress illumination for outdoor entries, breezeways, wash-down areas, and harsh indoor environments. Two adjustable 1 W LED heads provide up to 18 ft spacing on a 3 ft path (sample photometrics), powered by a 90-minute Ni-Cd battery. Its slim, UV-stable polycarbonate housing is UL 924 listed for wet locations, and the stainless hardware with waterproof shield/gasketing resists corrosion, hose-down spray, and impact. Explore more in our wet-location emergency lights.
Key Features
- Two fully adjustable 1 W LED heads; sample photometrics indicate 18 ft center-to-center on a 3 ft path at 7.5 ft mounting height (~12 ft on a 6 ft path).
- 90-minute emergency runtime with typical 24-hour recharge.
- Dual-voltage 120/277 VAC input; solid-state transfer, low-voltage disconnect (LVD), brownout protection, and push-to-test.
- UV-stable, corrosion-resistant thermoplastic (UL 94 V-0) and stainless hardware in a vandal-resistant design.
- Wet-location construction for damp, wet, and hose-down areas (gasketed shield and fasteners).
- Ceiling or wall mount: universal 3"/4" J-box pattern and rear keyholes; optional IHB bracket for poles, strut, and I-beams.
- Finishes: Black or White. Compact profile: 13.3" W × 5.8" H × 5.4" D.
Applications & Design Notes
Choose this model for sites that need a tough, compact wet-location LED egress fixture with straightforward installation and predictable spacing—exterior vestibules, covered landings, loading alcoves, rooftop access doors, cold-room anterooms (above 10 °C), and wash-down corridors. The 36° beam helps you cross-aim the two heads to overlap footprints and minimize shadows at stair treads and ramps. For projects requiring remote heads or higher wattage, consider remote-capable alternatives in our weatherproof emergency lights collection.
Related Wet-Location Guides
Spec Sheet
Download LEM54-N4 Emergency Light Spec Sheet (PDF)
Specifications (Overview)
- Listings: UL 924 emergency lighting; wet-location.
- Operation: 90-minute battery backup; typical 24 h recharge.
- Input: dual-voltage 120/277 VAC, 60 Hz.
- Heads: dual adjustable 1 W LED with ~36° beam.
- Housing: injection-molded, impact- and UV-resistant polycarbonate, UL 94 V-0.
- Temperature: 10–40 °C (50–104 °F).
Illumination
- Two high-intensity 1 W LED heads, rated for long life.
- Sample spacing: 18 ft center-to-center on a 3 ft path at 7.5 ft mounting height; ~12 ft on a 6 ft path (verify on site).
Electrical
- Maintenance-free Ni-Cd battery; 90-minute emergency runtime.
- Solid-state charger with automatic transfer, LVD, brownout sensing, and push-to-test.
- Dual-voltage 120/277 VAC input.
Mounting
- Rear keyholes and universal 3"/4" J-box pattern for ceiling or wall mount.
- Optional IHB bracket supports I-beam, strut, or pole mounting (field-installed).
Housing
- Injection-molded, impact- and UV-resistant polycarbonate with UL 94 V-0 flame rating.
- Waterproof shield and gasketing; stainless-steel hardware; vandal-resistant design.
- Finishes: White (
WH) or Black (BL).
Dimensions
- 13.3" W × 5.8" H × 5.4" D
Warranty / Listings
- 5-year warranty on electronics and housing; 5-year prorated Ni-Cd battery warranty.
- Meets UL 924, NEC, and NFPA 101 requirements.
Installation & Aiming Tips
- Mount around 7–9 ft and cross-aim heads to overlap beams on stairs, ramps, and landings.
- Confirm required foot-candle levels at the 90-minute mark (end-of-discharge) and adjust aiming as needed.
- Use the universal J-box pattern or the optional IHB bracket for poles and strut; seal any conduit penetrations for wet zones.
Compare With Other Wet-Location Emergency Lights
| Model (H1) | Heads / Output | Remote-Capable | Runtime | Ratings | Operating Temp | Best For |
|---|---|---|---|---|---|---|
| This model — Wet-Location LED Emergency Light – 1W Heads, Gasketed IP Housing | Dual 1 W LED heads | — | 90 min | UL 924 · Wet Location | ˜10–40 °C | Budget-minded installs; shorter spacing |
| Wet-Location LED Emergency Light – 3.7W Remote Option, IP Rated | Dual 1.9 W LED heads | 3.7 W (option) | 90 min | UL 924 · IP-rated | -20–50 °C | Parking decks; wash-down areas |
| Industrial Outdoor Emergency Light – Remote Capacity | Dual 1.875 W sealed LED | 3.7 W | 90 min | UL 924 · Wet Location | -20–50 °C | Docks; long runs with remote head |
| Wet Location Emergency Light – NEMA 4X – Dual MR16 Heads | Dual 3.6 W MR16 | Up to 46.8 W | 90 min | NEMA 4X · IP66 · UL 924 · NSF | to -25 °C (opt.) | Hose-down zones; multi-remote feeds |
| Wet-Location Semi-Recessed LED MR16 Emergency Unit | Dual 7 W MR16 | — | 90 min | UL 924 · Wet Location | ˜20–40 °C | Flush look; long-throw optics |
| Outdoor Wall-Pack Emergency Light – Decorative Die-Cast | Dual 6 W LEDs (AC 1,286 lm) | — | 90 min | UL 924 · Wet Location | 0–50 °C (to -30 °C w/ CW) | Entries needing dusk-to-dawn AC + egress |
FAQs
Can this unit be mounted on the ceiling outdoors?Yes. It supports wall or ceiling mount with a universal J-box pattern. Ensure the box is weather-tight and seal conduit penetrations for wet zones.
How do I achieve the 18 ft spacing noted?Mount around 7–8 ft and cross-aim the two heads to overlap beams. Always confirm foot-candle levels at 90 minutes under site conditions and local code.
Do I need a remote-capable model instead?This model is not remote-capable. If you need to drive remote heads from the fixture, consider a remote-capable wet-location unit or a higher-capacity NEMA 4X MR16 platform.
