Recessed Edge-lit Aluminum Exit Sign - Face: Single - Letter-Color: Red - Panel: Mirror

Recessed Edge-Lit Aluminum Exit Sign – Red or Green

This Recessed Edge-Lit Aluminum Exit Sign uses a clear acrylic panel to create a modern “floating” EXIT legend with red or green LEDs and Ni-Cd battery backup for reliable UL 924 egress. Explore the full Edge-Lit Exit Signs collection.

The RELZXTE recessed edge-lit aluminum EXIT sign pairs a low-profile extruded-aluminum housing with a crystal-clear acrylic panel for a clean, architectural look. Select red or green legend, expect ~90 minutes of emergency runtime, and install in drywall or grid ceilings with recessed kits for code-compliant egress in upscale interiors.

Download RELZXTE Exit Sign Spec Sheet (PDF)

Illumination

• Long-life red letter EXIT sign or green letter EXIT sign — field-selectable
• architectural edge-lit exit sign includes panel with glare-free, uniform lighting
• Double-face models include factory-installed mylar backer
• Self-adhesive directional arrows and template included

Electrical

• Dual-voltage 120/277 VAC input with push-to-test button and bi-color LED
• 4.8 V Ni-Cd battery (EM models) provides 90 minutes of emergency illumination
• Solid-state transfer switch; two-rate charger restores battery within 24 hours
• SPV version supports 208/220/240 VAC (50/60 Hz)

Mounting

• Recesses in drywall or T-bar ceiling grids with bar hangers included
• WM option available for recessed wall-mount applications
• Field-convertible to single-face or double-face exit signs

Housing / Trim

• Extruded-aluminum body with detachable trim for below-ceiling servicing
• Available in natural aluminum, white, or black powder-coat finish

Options

• 2C-120 / 2C-277 — Dual-circuit input (AC-only)
• SDT — automated self-testing exit sign
• USA — Buy American Act compliant
• CUSTOM — Special legends or graphics available

Warranty / Listings

• 5-year warranty on housing and electronics; battery prorated 5 years
• UL 924 listed for damp locations (0 °C – 50 °C)
• Complies with NFPA 101, NEC, OSHA, and CEC Title 20 standards

Dimensions

• Housing: 14 9/16 in W × 4? in D
• Trim height: 10 9/16 in

Frequently Asked Questions

Can I select the EXIT legend color?

Yes. The RELZXTE comes with a field-selectable LED panel, allowing you to choose either red or green EXIT lettering during installation.

Is this sign suitable for recessed ceiling installation?

Yes. The fixture includes a recessed chassis and bar hangers for drywall or T-bar ceilings. A WM option is available for recessed wall mount.

Does it include emergency backup?

EM models include a 4.8 V Ni-Cd battery that provides 90 minutes of emergency illumination during power outages.

Is it UL listed for damp locations?

Yes. The RELZXTE is UL 924 listed for damp locations and meets NFPA 101, NEC, and OSHA standards.

Can this unit be used in double-face configurations?

Yes. It ships as a convertible model and includes silver or white mylar backers for double-face use, with directional chevrons and a mounting template.
