REM Series – Recessed LED Emergency Lighting for Commercial Interiors

The REM LED Recessed Emergency Unit delivers flush-mounted, code-compliant emergency egress lighting for commercial interiors and damp-location corridors. With dual 1 W LED heads, a compact thermoplastic housing, and spacing up to 50 ft center-to-center on a 3 ft path at 12 ft mounting height, the REM Series offers reliable, low-profile performance for ceilings in drywall or T-bar grid applications.

Download REM LED Recessed Emergency Unit Spec Sheet (PDF)

Illumination

• Two Emergency Light ultra-bright 1 W LED heads with integrated reflector and lens assembly
• Delivers up to 50 ft spacing on a 3 ft egress path at 12 ft mounting height

Electrical

• Universal 120–277 VAC input with charge-status LED and push-to-test switch
• LED indicator: red = normal, off = battery fault
• 4.8 V NiMH or NiCd battery provides a minimum of 90 minutes of emergency illumination
• Automatic solid-state transfer switch and two-rate charger (24 h recharge)
• Input power: 2.0 W | 0.03 A (REM) • 2.5 W | 0.03 A (REM-SDT)

Mounting

• Recessed chassis with adjustable bar hangers for drywall or drop-ceiling grid
• Surface junction box pattern molded into housing for direct wiring

Housing / Trim

• Injection-molded, flame-retardant 5 VA thermoplastic housing in white or black
• Includes both rectangular and oval trim plates for field-selectable appearance

Options

• SDT — self-diagnostic testing (monthly, biannual, and annual cycles)

Warranty / Listings

• 5-year warranty on electronics and housing; battery prorated for 5 years
• UL 924 listed for damp locations (10 °C – 40 °C)
• CEC Title 20 compliant; meets NFPA 101, NEC, and OSHA requirements

Dimensions

• Rectangular trim: 14 ? in L × 11 13/16 in W × 3 5/16 in D
• Oval trim: 14 ? in L × 8 11/16 in W × 3 5/16 in D

Frequently Asked Questions

What is the emergency runtime of the REM Unit?

The REM Series provides 90 minutes of emergency lighting using a 4.8 V NiMH or NiCd rechargeable battery.

Is the REM fixture approved for use in damp locations?

Yes. It is UL 924 listed for damp environments and meets all major compliance codes including NFPA 101, NEC, OSHA, and CEC Title 20.

What ceiling types are compatible with the REM emergency unit?

The REM can be installed in both drywall and T-bar drop ceilings. Bar hangers are included for quick and secure mounting.

Does the REM come with different trim options?

Yes. Both oval and rectangular trim plates are supplied for flexibility in appearance during field installation.

Can I order the REM with self-diagnostics?

Yes. The REM-SDT version includes self-testing capabilities that automatically perform monthly, semiannual, and annual diagnostics per UL requirements.

Product Features

• Brand: Best Lighting
• Damp Location
• Housing Color: Black
• Housing Color: White
• LED
• Low Profile
• Product: REM
• Recessed Lights
• Self Testing
• Thermoplastic
• Emergency Lights
