Recessed LED Emergency Lighting for Commercial Interiors

Recessed LED Emergency Light - Dual 1W Heads, Up to 50 ft Spacing, NiMH/NiCd 90 min, 120/277V - Features & Specs

The REM recessed LED emergency light delivers flush-mounted, code-compliant egress lighting for commercial interiors. Dual 1 W LED heads, a compact thermoplastic housing, and spacing up to 50 ft center-to-center on a 3 ft path at 12 ft mounting height make it a reliable, low-profile choice for drywall or T-bar ceilings. Explore more recessed LED emergency lighting and damp location emergency lights.

Key Features

• UL 924 listed; damp location rated (10–40 °C)
• Recessed, flush-mount chassis for drywall or T-bar grid ceilings
• Dual 1 W LED heads; spacing up to 50 ft on a 3 ft path at 12 ft mount
• Universal input 120–277 VAC; status LED & push-to-test
• Battery: 4.8 V NiMH or NiCd; 90 min emergency runtime
• Solid-state transfer; two-rate charger (~24 h full recharge)
• Includes rectangular & oval trim plates (field-selectable)
• Low-profile 5VA thermoplastic housing (white or black)
• Option: SDT self-diagnostics (monthly/biannual/annual)
• Compliance: NFPA 101, NEC, OSHA; CEC Title 20

Spec Sheet

Download REM LED Recessed Emergency Unit Spec Sheet (PDF)

Illumination

• Two ultra-bright 1 W LED heads with integrated reflector/lens assembly
• Spacing up to 50 ft on a 3 ft egress path at 12 ft mounting height

Electrical

• 120–277 VAC universal input with charge-status LED and push-to-test
• Bi-color LED: green = normal; red = battery fault
• 4.8 V NiMH or NiCd battery; minimum 90-minute emergency illumination
• Automatic solid-state transfer; two-rate charger (~24 h full recharge)
• Input power: 2.0 W | 0.03 A (REM) · 2.5 W | 0.03 A (REM-SDT)

Mounting

• Recessed chassis with adjustable bar hangers for drywall or T-bar grid
• Surface junction-box pattern molded into housing for direct wiring

Housing / Trim

• Injection-molded, flame-retardant 5VA thermoplastic (white or black)
• Includes both rectangular and oval trim plates (field-selectable)

Options

• SDT — self-diagnostic testing (monthly, biannual, annual)

Warranty / Listings

• 5-year warranty on electronics and housing; battery prorated 5 years
• UL 924 listed for damp locations (10 °C–40 °C)
• CEC Title 20 compliant; meets NFPA 101, NEC, OSHA

Dimensions

• Rectangular trim: see spec sheet for exact dimensions
• Oval trim: see spec sheet for exact dimensions

Frequently Asked Questions

What is the emergency runtime?

The REM provides a minimum of 90 minutes of illumination using a 4.8 V NiMH or NiCd battery.

Is it rated for damp locations?

Yes. It is UL 924 damp-location listed and meets major codes including NFPA 101, NEC, OSHA, and CEC Title 20.

Which ceiling types are supported?

Designed for drywall and T-bar grid ceilings; adjustable bar hangers are included for secure mounting.

Does it include multiple trim options?

Yes. Both oval and rectangular trim plates are supplied to match interior aesthetics.

Can I order self-diagnostics?

Yes. Choose the REM-SDT version for automatic monthly, biannual, and annual self-tests.
