Remote-Capable LED Exit Sign - Field-Selectable Red/Green

SKU: CEXTEU3RW
$59.83

Got questions?

Give us a call 800-847-1955!

Remote-Capable Thermoplastic LED Exit Sign — 3.0 W Remote Output, Red/Green Legend, Ni-Cd 90 min, 120/277 V — Features & Specs

The CEXTEU Remote-Capable LED Exit Sign delivers bright, code-legible wayfinding in a compact, flame-rated thermoplastic cabinet with the flexibility of 3.0 W remote-head output. A universal backplate and EZ-snap canopy simplify wall, top, or end mounting, while the 3.6 V Ni-Cd pack supplies 90-minute emergency operation. Select a red or green legend, add SDT self-testing for automated diagnostics, or choose SPV 120/230 V for international mains. For related choices, see our exit signs with built-in remote output.

UL 924 LED Legend Ni-Cd / 90 min 120/277 V Remote 3.0 W Self-Testing (Opt.) Red / Green Damp Location

Key Features

  • UL 924 listed exit sign; damp-location rated (0–40 °C / 32–104 °F).
  • Field-selectable red or green legend; ships single-face with field conversion to double-face.
  • Remote-capable output up to 3.0 W to power compatible remote heads.
  • 3.6 V Ni-Cd battery with 90-minute emergency runtime; two-rate charger (~24 h recharge).
  • Universal 120/277 V input; optional SPV 120/230 V for international services.
  • Bi-color status LED (normal/fault) and push-to-test; solid-state transfer driver.
  • UL 94 5VA flame-rated thermoplastic housing (white or black); snap-out chevrons.
  • Options: SDT self-testing diagnostics; SPV special-voltage input.
  • 5-year warranty on electronics & housing; battery 5-year prorated; CEC Title 20 compliant.

Applications & Design Notes

Choose CEXTEU when you need a slim, economical exit sign that can extend egress illumination a few feet beyond the doorway or around a corner. Typical placements include elevator lobbies, intersecting corridors, small vestibules, and stair landings with a “dead-spot” just off the threshold. The 3.0 W remote budget supports a single higher-output remote or two ultra-compact heads—ideal when a full combo is excessive but a standalone emergency light would clutter the wall.

Plan remote loads by sum of head watts. Keep total = 3.0 W and size conductors to curb voltage drop on longer runs. Where bid specs call for uniform signage, match legend color to the floor standard, select double-face where approach occurs from both directions, and set chevrons during rough-in to lock directionality. If the project requires heavier abuse resistance or jurisdictional particulars, a steel exit sign or a Chicago-approved model is often the right alternate.

Related Remote-Capable Guides

Remote Heads — Sizing, Wiring & Voltage-Drop (Calculator) Self-Testing Exit Signs — Benefits & Compliance

Spec Sheet

Download CEXTEU Remote-Capable Exit Sign Spec Sheet (PDF)

Specifications (Overview)

  • Legend: Red or green EXIT; single-face (field-convertible to double-face); snap-out chevrons.
  • Remote Output: up to 3.0 W (RC) for compatible remote heads.
  • Listings: UL 924 emergency signage; damp-location rated (0–40 °C).
  • Housing: UL 94 5VA thermoplastic; white or black finish.

Illumination

  • Long-life LEDs provide uniform legend visibility with high contrast in smoke-dimmed conditions.
  • Use the RC budget to power adjacent remote heads where extra egress light is needed beyond the sign’s face visibility.

Electrical

  • Dual-voltage 120/277 V input; optional SPV 120/230 V model (50/60 Hz).
  • 3.6 V Ni-Cd battery; 90-minute emergency operation; solid-state transfer.
  • Two-rate automatic charger restores full capacity in approximately 24 hours.
  • Bi-color status LED (green = normal / red = service) and push-to-test for fast checks.
  • RC output: 3.0 W total—size heads and wiring to remain within budget and limit voltage drop.

Mounting

  • Top/End: EZ-snap canopy mates to standard J-box patterns.
  • Wall: universal knockout backplate supports surface mount without special adapters.

Housing / Finish

  • Injection-molded, impact-resistant UL 94 5VA thermoplastic for a lightweight yet durable enclosure.
  • Finish options: white or black to coordinate with interior palettes.

Options

  • SDT — self-testing diagnostics (monthly / semi-annual / annual) for automated compliance logs; see self-diagnostic exit signage.
  • SPV 120/230 V — special-voltage input for facilities on 230 V mains (maintains listing without field transformers).
  • Pair with compatible LED remote heads sized to the 3.0 W RC budget.

Certifications / Warranty

  • UL 924 listed; damp-location rating (0–40 °C).
  • Meets NFPA 101, NEC, and OSHA; CEC Title 20 compliant.
  • 5-year warranty on electronics & housing; Ni-Cd battery 5-year prorated.

Dimensions

Installation & Code Tips

  • Arrow setup: Set chevrons to match the approved egress direction; document left/right/double in submittals.
  • RC budgeting: Sum the rated watts per head; keep the total = 3.0 W. Shorter runs and appropriate wire gauge help minimize voltage drop.
  • Testing cadence: Allow a full charge before performing the initial 90-minute discharge. Log monthly functional checks and annual full-duration tests.
  • Face selection: Use double-face where occupants approach from both directions (e.g., at corridor intersections).
  • International mains: Specify SPV 120/230 V to maintain listing without a step-down transformer.

Compare Remote-Output EXIT Signs by Budget Tier & Housing

RC-only exit signs contrasted by remote watts, legend configuration, input options, and housing style (no pricing).

Model (H1) Remote Budget Legend / Faces Mount Options Input Choices Diagnostics Housing Style When to Choose
This model — CEXTEU remote-capable LED exit sign 3.0 W RC Red/Green; single ? double (field) Wall · Top/End canopy 120/277 V; SPV 120/230 V opt. SDT (optional) Thermoplastic, slim Small “dark pockets” near doors; budget retrofits
Remote-output exit sign — 5.5 W class (CEMXTE) 5.5 W RC Red/Green; single/double Wall · Top/End canopy 120/277 V; SPV opt. SDT (optional) Thermoplastic, low-profile Longer remote throws; two-head remote runs
Chicago steel EXIT/STAIR — non-RC baseline (CAXTE) — (not RC) 6" red; single/double Wall · Top/End steel canopy 120/277 V — Steel, rugged AHJ/Chicago jobs; heavier-duty interiors
Edge-lit EXIT/STAIR — architectural, non-RC — (not RC) 8" red; single/double Surface canopy (edge-lit) 120/277 V — Aluminum, edge-lit Architectural corridors; aesthetic priority

Frequently Asked Questions

What does “remote-capable” mean for the CEXTEU?

It means the internal battery/driver can power external remote heads up to a total of 3.0 W. Use this to illuminate a nearby alcove, vestibule, or short corridor segment without adding a full combo unit.

How do I size remote heads to the 3.0 W budget?

Check each head’s rated watts and sum the load. Keep the total = 3.0 W. Use shorter runs and appropriate wire gauge to minimize voltage drop and maintain performance.

Can I run on 230 V mains?

Yes—specify the SPV 120/230 V model to maintain listing and avoid external step-down transformers.

Is self-testing available?

Yes. The SDT option automates monthly, semi-annual, and annual tests with status indication for maintenance logs and audits.

When should I choose double-face?

Use double-face where occupants approach from both directions (e.g., corridor intersections); otherwise single-face reduces load and visual clutter.

  • remote-capable exit sign 3.0 W
  • thermoplastic LED exit signage
  • Ni-Cd 90-minute UL 924 sign
  • self-diagnostic exit sign SDT
  • SPV 120/230 V special-voltage input

Buying support

Product details and buying checks

Review specs, documents, buying checks, compatible products, and FAQs before ordering.

  • UL 924
  • LED Legend
  • Ni‑Cd / 90 min
  • 120/277 V
  • Remote 3.0 W
  • Self‑Testing (Opt.)
  • Red / Green
  • Damp Location
  • NFPA 101
  • OSHA

Key features

  • UL 924 listed exit sign; damp‑location rated ( 0–40 °C / 32–104 °F ).
  • Field‑selectable red or green legend; ships single‑face with field conversion to double‑face .
  • Remote‑capable output up to 3.0 W to power compatible remote heads.
  • 3.6 V Ni‑Cd battery with 90‑minute emergency runtime; two‑rate charger (~ 24 h recharge).
  • Universal 120/277 V input; optional SPV 120/230 V for international services.
  • Bi‑color status LED (normal/fault) and push‑to‑test; solid‑state transfer driver.
  • UL 94 5VA flame‑rated thermoplastic housing (white or black); snap‑out chevrons.
  • Options: SDT self‑testing diagnostics; SPV special‑voltage input.
  • 5‑year warranty on electronics & housing; battery 5‑year prorated; CEC Title 20 compliant.
Product family Exit Signs
SKU CEXTEU3RW
Listing UL 924
Power 120/277 V input; optional SPV 120/230 V for international services

Documents

Applications & Design Notes

Use CEXTEU for indoor commercial egress routes that need a compact UL 924 exit sign with battery backup and optional low-wattage remote-head capacity. Good fits include elevator lobbies, intersecting corridors, small vestibules, stair landings, and doorway areas where the EXIT legend handles wayfinding and a nearby remote head can cover a small dark spot. This is a thermoplastic, damp-location exit sign for wall, ceiling, or end mounting; it is not a steel or wet-location exit sign. Keep connected remote load at or below the 3.0 W RC budget, match red or green legend color to project/AHJ requirements, choose single- or double-face configuration based on approach direction, and set chevrons during rough-in.

  • Best fit: indoor/damp commercial exit signage with optional nearby remote-head coverage.
  • Avoid using as a wet-location, outdoor, vandal-resistant, or steel-exit-sign substitute.
  • Remote output: keep compatible remote heads within the 3.0 W budget and account for voltage drop.
Related Remote‑Capable Guides

Remote Heads — Sizing, Wiring & Voltage‑Drop (Calculator) Self‑Testing Exit Signs — Benefits & Compliance

Spec Sheet

Download CEXTEU Remote‑Capable Exit Sign Spec Sheet (PDF)

Specifications (Overview)
  • Legend: Red or green EXIT; single‑face (field‑convertible to double‑face); snap‑out chevrons.
  • Remote Output: up to 3.0 W (RC) for compatible remote heads.
  • Listings: UL 924 emergency signage; damp‑location rated ( 0–40 °C ).
  • Housing: UL 94 5VA thermoplastic; white or black finish.
Illumination
  • Long‑life LEDs provide uniform legend visibility with high contrast in smoke‑dimmed conditions.
  • Use the RC budget to power adjacent remote heads where extra egress light is needed beyond the sign’s face visibility.
Electrical
  • Dual‑voltage 120/277 V input; optional SPV 120/230 V model (50/60 Hz).
  • 3.6 V Ni‑Cd battery; 90‑minute emergency operation; solid‑state transfer .
  • Two‑rate automatic charger restores full capacity in approximately 24 hours .
  • Bi‑color status LED (green = normal / red = service) and push‑to‑test for fast checks.
  • RC output: 3.0 W total—size heads and wiring to remain within budget and limit voltage drop.
Mounting
  • Top/End: EZ‑snap canopy mates to standard J‑box patterns.
  • Wall: universal knockout backplate supports surface mount without special adapters.
Housing / Finish
  • Injection‑molded, impact‑resistant UL 94 5VA thermoplastic for a lightweight yet durable enclosure.
  • Finish options: white or black to coordinate with interior palettes.
Options
  • SDT — self‑testing diagnostics (monthly / semi‑annual / annual) for automated compliance logs; see self‑diagnostic exit signage .
  • SPV 120/230 V — special‑voltage input for facilities on 230 V mains (maintains listing without field transformers).
  • Pair with compatible LED remote heads sized to the 3.0 W RC budget.
Certifications / Warranty
  • UL 924 listed; damp‑location rating ( 0–40 °C ).
  • Meets NFPA 101 , NEC , and OSHA ; CEC Title 20 compliant.
  • 5‑year warranty on electronics & housing; Ni‑Cd battery 5‑year prorated .
Compliance notes
  • Confirm final fixture placement, runtime, and local AHJ acceptance for the project.
