Semi-Recessed MR-16 LED Emergency Lighting Unit
Semi-Recessed MR-16 LED Emergency Lighting Unit

Semi-Recessed MR-16 LED Emergency Lighting Unit

SKU: RMR-16-PLED
$78.30

Got questions?

Give us a call 800-847-1955!

Semi-Recessed MR-16 LED Emergency Lighting Unit

The RMR-16-PLED Semi-Recessed LED MR-16 Emergency Unit installs flush in drywall or drop ceilings and features dual 7 W MR-16 LED heads optimized for long-throw emergency egress lighting. With up to 76 ft center-to-center spacing on a 3 ft path, universal 120/277 VAC input, and a 6 V SLA battery with 90-minute backup, this unit delivers reliable performance in architecturally sensitive or damp-location commercial interiors. For more low-profile ceiling-mounted solutions, browse our full range of Recessed Emergency Lights.

NYC Approved UL 924 Dual 7 W MR16 Up to 76 ft 6V SLA / 90 min 120/277V Semi-Recessed Damp Location Self Testing (Opt.)

Key Features

  • UL 924 listed; damp-location rated (20–40 °C)
  • Dual 7 W MR-16 LED heads; spacing up to 76 ft (3 ft path @ 7.5 ft)
  • Universal input 120/277 VAC; charge/power LED & push-to-test
  • Battery: 6 V SLA; 90 min emergency runtime; LVD protection
  • Solid-state transfer; two-rate charger (~24 h full recharge)
  • Semi-recessed chassis with bar hangers for drywall or T-bar ceilings
  • Universal backplate for surface/wall mount; ½" conduit knockout
  • High-impact 5 VA thermoplastic housing (white or black)
  • Options: SDT self-diagnostics; USA (BAA) assembly
  • Compliance: NFPA 101, NEC, OSHA
  • Warranty: 5-year electronics/housing; battery 2-year prorated

RMR-16-PLED Spec Sheet PDF Icon Download LED Emergency Lighting Unit Spec Sheet (PDF)

Illumination

  • Two fully adjustable Emergency Light 7 W LED MR-16 lamp heads
  • Precision optics for long spacing — up to 76 ft on 3 ft path at 7.5 ft height

Electrical

  • Dual-voltage 120/277 VAC input
  • 6 V maintenance-free sealed lead-acid battery with 90-minute emergency runtime
  • Low-voltage disconnect (LVD) and bi-color LED status indicator
  • Solid-state transfer switch and two-rate charger (24 h full recharge)
  • Input load: 6.0 W @ 120 V • 6.2 W @ 277 V

Mounting

  • Semi-recessed chassis with adjustable bar hangers for ceiling grids and drywall
  • Universal knockout backplate for surface or wall mounting
  • ½ in conduit knockout provided for side feed

Housing

  • Injection-molded 5 VA flame-retardant thermoplastic housing — white or black

Options

Warranty / Listings

  • 5-year warranty on electronics and housing; 2-year prorated battery
  • UL 924 listed for damp locations (20 °C – 40 °C)
  • NFPA 101, NEC, OSHA compliant

Dimensions

  • 13¾ in L × 5 ? in W × 3 in D (see spec-sheet for diagram)

Frequently Asked Questions

Where is the RMR-16-PLED emergency unit typically installed?

The RMR-16-PLED is designed for recessed installation in drywall or T-bar ceilings, making it ideal for offices, retail spaces, and other commercial interiors.

How far apart can I space these emergency lights?

With its dual 7 W MR-16 heads, this unit provides up to 76 ft of center-to-center coverage on a 3 ft wide egress path at a 7.5 ft mounting height.

Does this unit support self-testing diagnostics?

Yes. You can choose the SDT option for automated monthly, semi-annual, and annual diagnostics to comply with safety testing codes.

Is this product UL listed for damp locations?

Yes. It is UL 924 listed for damp-location emergency light use and meets all applicable safety codes including NFPA 101, NEC, and OSHA.

Can this emergency light be wall mounted?

Yes. In addition to ceiling installation, the universal knockout backplate supports surface wall mounting when needed.
