Steel Housing LED Emergency Light – Dual Heads, Remote-Capable, NYC
The RS2 Series 27 W Steel LED Emergency Light combines a rugged 20-gauge cabinet from our steel emergency lights collection with two fully adjustable 1.5 W LED lamp heads. Designed to meet NYC-approved emergency lights requirements, this unit delivers reliable egress lighting with up to 8 hours runtime (without remotes) or 20 W remote-capable output. Universal 120/277 VAC input, a sealed lead-calcium battery, and smart charger electronics ensure dependable performance in stairwells, corridors, and industrial spaces.
Specs, documents, buying checks, accessories, and FAQs are organized below from product fields for easier review.
Buying support
Product details and buying checks
Review specs, documents, buying checks, compatible products, and FAQs before ordering.
- UL 924
- 120/277 VAC
- 27 W Output
- 20 W Remote-Capable
- Dual / Adjustable Heads
- Steel Cabinet
- Damp Location
- NYC Compliant
- 90 min Battery
- NFPA 101
Key features
- Dual 1.5 W LED heads (12 LEDs/head) with precision optics for even egress coverage.
- 20 W DC remote capacity — powers up to four compatible MLED remote heads (load-dependent).
- Runtime up to 8 hours when no remote loads are connected; 90-minute code runtime standard.
- Dual-voltage 120/277 VAC input with solid-state charging, LVD, and short-circuit protection.
- Sealed lead-calcium battery; front test button and bi-color status LED.
- Die-formed 20 ga steel cabinet in White (WH) or Black (BL) .
- Designed to meet NYC requirements; UL 924 listed for damp locations.
Documents
Related NYC Emergency Light Guides
NYC Emergency Lighting Requirements US Fire Codes – NYC Compliance Guide
Spec Sheet
Download RS2 Steel LED Series Spec Sheet (PDF)
Photometrics
- 7.5 ft mounting height 3 ft path — 18 ft on-center spacing
- 6 ft path — 16 ft on-center spacing
Electrical
- Universal 120/277 VAC , 60 Hz input
- Maintenance-free sealed lead-calcium battery — 90-minute emergency runtime; ~ 24-hour recharge
- Solid-state charging with low-voltage disconnect and short-circuit protection
- Dual-color LED status indicator and front-mounted push-to-test
Construction / Finish
- Die-formed 20-gauge steel cabinet with epoxy powder-coated finish
- Finishes: White (WH) or Black (BL)
- Dimensions: 12.25" W × 11.38" H × 2.50" D
Mounting
- Shelf mount or wall mount via universal J-box pattern with rear keyholes
- Top, back, and side knockouts for conduit entry or side-mounted heads
Options & Accessories
- Indoor remotes: MLED1-W , MLED2-W
- Outdoor remotes: MLED1-G-WP , MLED2-G-WP
- Protective guards: WG-S wire guard; XG-PS poly guard
- Guardian™ G2 self-diagnostics (factory option)
Warranty
- 5-year warranty on electronics & housing; battery 5-year prorated
Certifications
- UL 924 listed for damp locations
- Compliant with NFPA 101 Life Safety Code, NEC , and OSHA regulations
- Meets City of New York emergency code requirements
Compliance notes
- Confirm final fixture placement, runtime, and local AHJ acceptance for the project.
