Die-Cast Aluminum LED Thin Exit Sign
Regular price
$114.95
Couldn't load pickup availability
Got questions?
Give us a call 1-888-959-1965!
Thin Die-Cast Aluminum LED Exit Sign Overview
The KXTEU thin die-cast aluminum LED exit sign is a low-profile metal EXIT sign for commercial interiors that need a cleaner, more durable housing than standard thermoplastic. This UL 924 die-cast aluminum exit sign family supports red or green letter exit sign layouts, single-face, double-face, and universal face configurations, plus white, black, or aluminum finish combinations for the housing and face panel.
Need a thin metal exit sign instead of a thermoplastic box? This die-cast aluminum LED exit sign is for commercial interiors where a slimmer metal housing, durable finish, and clean EXIT legend matter. Use it for corridors, offices, retail, tenant improvements, and public-facing egress paths where a standard thermoplastic sign feels too bulky. Compare Die-Cast Aluminum Exit Signs, browse Exit Signs, or read the Die-Cast Aluminum Exit Signs Guide before choosing the exact model and battery-backup configuration.
Universal 120/277 V electronics and canopy hardware support wall, ceiling, or end mounting, making KXTEU a strong universal mount exit sign for offices, retail suites, schools, hospitality corridors, healthcare support spaces, and public interiors. Select options turn it into a 90-minute battery backup exit sign, self diagnostics exit sign, dual-circuit exit sign, tamper proof exit sign, assembled in USA exit sign, or damp-location die-cast exit sign. Compare related Die-Cast Aluminum Exit Signs, browse all Exit Signs, or review UL 924 compliance guidance.
Specs, documents, buying checks, compatible paths, and FAQs are organized below from product fields for easier review.
Buying support
Product details and buying checks
Review specs, documents, buying checks, compatible product paths, and FAQs before ordering.
- UL 924
- Die-Cast Aluminum
- Thin Profile
- Red / Green Legend
- Single / Double / Universal Face
- 120/277 V
- Ni-Cd / 90 min Option
- Self Diagnostics (Opt.)
- Dual Circuit (Opt.)
- Tamper Proof (Opt.)
- Assembled in USA (Opt.)
- Universal Mount
- Damp Location
- CEC Title 20
Key features
- Thin die-cast aluminum LED exit sign with a premium low-profile metal housing for commercial interiors.
- Red or green LED EXIT legend options support building plans, existing signage standards, and local code preference.
- Single-face, double-face, and universal face configurations cover one-direction and two-direction visibility requirements.
- White, black, and aluminum housing and face-panel finish combinations support architectural interior coordination.
- UL 924 listed for emergency egress signage and damp-location rated from 0-50 deg C.
- Dual-voltage 120/277 V input supports common commercial branch circuits.
- Optional 4.8 V Ni-Cd battery backup provides 90-minute emergency operation with about 24-hour recharge.
- Optional SDT self diagnostics supports automated inspection routines.
- Optional 2C-120 or 2C-277 dual-circuit AC configurations support separate normal and emergency feeds where specified.
- Optional TP tamper proof hardware helps limit unauthorized access in public or high-traffic interiors.
- Assembled in USA variants are available for projects with domestic-assembly requirements.
- Canopy and rear knockouts support ceiling, end, or wall mounting with snap-out chevrons for directional arrows.
Documents
Best Applications
Choose KXTEU for commercial interiors where a thin metal exit sign looks better and feels sturdier than standard thermoplastic. Common applications include offices, hospitality corridors, retail suites, schools, healthcare support spaces, tenant improvements, and public-facing egress paths.
Face, Legend, and Finish Selection
- Choose red or green EXIT letters to match building plans, existing building signage, and local code preference.
- Use single-face configurations where occupants approach the sign from one direction.
- Use double-face or universal face configurations where the sign must be visible from two directions.
- Coordinate white, black, or aluminum housing and face-panel finishes with the surrounding wall, ceiling, or door hardware.
Power and Runtime Checks
- Standard 120/277 V input supports common commercial branch circuits.
- Choose EM battery-backup variants where the sign needs local 90-minute emergency operation.
- Choose 2C-120 or 2C-277 dual-circuit variants where building plans call for separate normal and emergency feeds instead of local battery backup.
- Allow battery models to complete the recharge period before performing a full discharge test after installation.
Mounting Orientation Checks
- Wall mount where one-direction visibility above a door or path-of-travel point is sufficient.
- Ceiling mount where the sign must be visible from below or along a corridor approach.
- End mount where the sign must project perpendicular to the wall surface.
- Confirm viewing distance, obstruction clearance, arrow direction, and local code approval before closeout.
Options and Maintenance
Use SDT self diagnostics when the owner wants automated test support. Use TP tamper proof hardware in public or high-traffic spaces where unauthorized access is a concern. Use assembled in USA variants when the project requires domestic assembly documentation.
Compare Similar Exit Sign Paths
- Choose die-cast aluminum exit signs for premium metal construction and a low-profile architectural look.
- Choose battery-backup exit signs when each sign needs onboard 90-minute emergency runtime.
- Choose self-testing exit signs when maintenance teams want automated inspection support.
- Choose wet-location exit signs for exposed exterior, rain, spray, or washdown applications.
Project Paperwork and Closeout Checks
Before ordering, confirm face count, red or green legend color, housing finish, face-panel finish, battery or dual-circuit requirement, diagnostics, tamper proof hardware, assembled in USA requirement, arrow direction, mounting location, and final local code approval.
Compliance notes
- Confirm final face count, legend color, housing finish, face-panel finish, battery or dual-circuit requirement, arrow direction, mounting location, and local code approval against the building plans.
- Use a wet-location exit sign for exposed exterior, rain, spray, or washdown conditions.
- Select an EM battery-backup option where local 90-minute emergency operation is required.
- Dual-circuit AC variants should be reviewed against the electrical design because they are not the same as local battery-backup variants.
Frequently asked questions
Is KXTEU a thin die-cast aluminum LED exit sign?
Yes. KXTEU is a thin die-cast aluminum LED exit sign family for commercial interiors that need a premium low-profile metal housing and UL 924 egress signage.
Can I choose red or green EXIT letters?
Yes. The KXTEU matrix includes red and green LED letter configurations. Match the letter color to the building plans, existing signage, and local code requirements.
Is this available as single-face, double-face, or universal face?
Yes. KXTEU includes single-face, double-face, and universal face configurations so the same product family can cover one-direction and two-direction visibility requirements.
Can this exit sign be wall, ceiling, or end mounted?
Yes. The canopy and rear knockouts support wall, ceiling, or end mounting, with snap-out chevrons for directional arrow setup.
Which variants include 90-minute battery backup?
Variants with EM battery backup include a 4.8 V Ni-Cd battery for 90 minutes of emergency operation. Dual-circuit variants are AC-fed configurations and should not be treated as battery-backup models.
What do SDT, 2C, TP, and USA mean?
SDT indicates self diagnostics, 2C indicates dual-circuit AC, TP indicates tamper proof hardware, and USA indicates assembled in USA variants.
Is KXTEU suitable for wet or outdoor locations?
No. KXTEU is damp-location rated for protected indoor applications. Use a wet-location exit sign for exposed exterior, rain, spray, or washdown conditions.
When should I choose die-cast aluminum instead of thermoplastic or edge-lit?
Choose die-cast aluminum when the project needs a premium metal housing and low-profile surface-mounted look. Choose thermoplastic for budget-focused interiors, and choose edge-lit when the desired look is an acrylic panel with a floating EXIT legend.
