Edge-Lit Recessed Exit Sign – Stair, 8" Red Letters

SKU: CARELZXTE1RWW-NA
$157.55

Got questions?

Give us a call 800-847-1955!

Chicago-Approved Recessed Edge-Lit EXIT / STAIR Sign — 8" Red Letters, 120-min Ni-Cd, 120/277 V, Ceiling Trim — Features & Specs

This recessed edge-lit EXIT / STAIR sign delivers uniform LED illumination with a Ni-Cd emergency pack for reliable UL 924 egress. Install flush in drywall or T-bar ceilings using the included bar hangers; an optional WM trim supports recessed wall-mount applications. Compare models in our Edge-Lit Exit Signs lineup, or view jurisdictional options under Chicago-Approved Exit Signs.

Chicago Approved UL 924 Edge-Lit Acrylic Recessed Mount Ni-Cd · 120 min 120/277 V Damp Location

Key Features

  • City of Chicago–approved; UL 924 emergency signage.
  • 8" red EXIT or STAIR legend on a clear, edge-lit acrylic panel for uniform, low-glare visibility.
  • Recessed ceiling installation in drywall or T-bar grids; bar hangers included.
  • Field-selectable single- or double-face; chevrons supplied (left / right / double).
  • Dual-voltage input, status indicator, and push-to-test with solid-state transfer.
  • Extruded-aluminum construction with detachable trim for below-ceiling access.

Applications & Design Notes

Specify this recessed Chicago edge-lit sign to keep corridors and stair runs clean and architectural while meeting city letter-height and contrast requirements. The slim profile reduces corridor clutter; the detachable trim lets you service batteries and boards from below the ceiling. Use the WM trim where a flush wall reveal is preferred (e.g., stair landings).

Related Edge-Lit Guides

Recessed Edge-Lit: Ceiling Trim & 8" Letters Plan Single vs Double-Face (Edge-Lit)

Spec Sheet

Download CARELZXTE Edge-Lit Exit Sign Spec Sheet (PDF)

Specifications (Overview)

  • Listings: Chicago approved; UL 924; damp-location rated.
  • Legend: EXIT or STAIR; 8" letter height; 3/4" stroke (Chicago).
  • Operation: 120-minute emergency illumination (EM models); automatic transfer on power loss.
  • Serviceability: below-ceiling access via detachable trim (white or natural finish).

Illumination

  • Long-life white LEDs coupled to an edge-lit acrylic panel for even legend brightness.

Electrical

  • 120/277 V input with bi-color status LED and push-to-test.
  • 4.8 V Ni-Cd (EM) — up to 120 minutes emergency runtime; two-rate charger (~24 h recharge).
  • Input (EM): 4.5 W / 0.042 A @ 120 V • 4.9 W / 0.020 A @ 277 V.

Mounting

  • Recesses into drywall or T-bar ceilings; adjustable bar hangers included.
  • WM trim kit enables recessed wall-mount applications.
  • Self-adhesive chevrons for field arrow configuration (left / right / double / none).

Housing / Trim

  • Extruded-aluminum body with detachable trim (white or natural).

Options

  • WM — recessed wall-mount trim kit.
  • EXIT or STAIR legends; arrows: none / left / right / double.

Warranty / Listings

  • 5-year warranty on electronics & housing; battery prorated 5 years.
  • Meets NFPA 101, NEC, OSHA; damp-location rating 0–50 °C.

Dimensions

  • Housing: 15 ¾" W × 3 ¼" D
  • Ceiling opening: approx. 14 ½" W
  • Trim: 12 ½" H · depth approx. 4 ½"

Installation Tips

  • Lay out for clear sightlines at turns and landings; verify visibility from both approaches.
  • Apply chevrons during rough-in to match the approved egress direction; document in submittals.
  • Record a full 120-minute discharge test at commissioning.

Compare With Other Edge-Lit Exit Signs

Model (H1) Legend / Letters Faces Mounting Approvals Best For
This model — Edge-Lit Recessed Exit Sign – Stair, 8" Red Letters STAIR or EXIT · 8" red Single / Double Recessed ceiling (WM trim for recessed wall) Chicago · UL 924 · Damp Flush aesthetic in Chicago corridors & stairs
Edge-Lit Exit Sign – Stair, Aluminum, 8" Red STAIR · 8" red Single / Double Surface (top / end / back canopy) Chicago · UL 924 · Damp Where recessed framing isn’t available
Edge-Lit Exit Sign – Recessed, NYC 8" Red Letters EXIT · 8" red Single Recessed ceiling NYC · UL 924 · Damp New York City corridors (NYC spec)
Edge-Lit LED Exit Sign – Surface & Recessed Mounting EXIT · red/green (varies) Single / Double Surface or recessed UL 924 · Damp Flexible projects needing both mount types
Edge-Lit Running-Man Exit Sign – Surface or Recessed, CSA Listed Running-Man legend Single / Double Surface or recessed CSA · Damp Canadian code applications
Explosion-Proof Edge-Lit LED Exit Sign – Class I Div 1 EXIT · red Single Surface / pendant (varies) C1D1 · UL 924 Hazardous / industrial areas
