400W HPS Shoebox Area Light

400W HPS Shoebox Area Light


Our 16-inch 400W HPS shoebox area lights mix an appealing design with robust watertight construction. They have a factory sealed aluminum housing with a hinged aluminum lens frame. The lens itself is made of tempered glass which is very difficult to break and protects the high pressure sodium vapor lamp inside.

This 400W HPS shoebox area light is made for all types of outdoor environments and is powder coated with an architectural bronze finish, maximizing its resistance to the elements. The WP301-HPS-400 is UL Listed for Wet Locations and has a CWA ballast that maintains the temperature and voltage of the HPS lamp, keeping it at maximum efficiency for up to 10,000 hours!

Thinking about purchasing our popular WP301-HPS-400? Call us anytime 24/7 at 800-839-4734 to speak to a live representative. For more detailed questions or to obtain a quote, email our production team.

Key Features

  • Minimum operating temperature: 30°C (-22°F)
  • HPS lamps rated at 10,000 hours of use
  • Dark Sky Compliant
  • Buy America Approved
  • UL Listed for Wet Locations

Electrical Specification

  • Multi-tap - 120/208/240/277VAC
  • Optional 480VAC input (please specify)
  • Pulse Start CWA ballast

Reflector Options

  • IES Type 5
  • Forward Throw
  • Wide Angle
  • Full Cutoff
  • Horizontal Mount
  • Cobra Style

Mounting Options

  • 6" Pole Bracket (standard)
  • Large Mounting Yoke
  • Slip Fitter
  • Swivel Bracket
  • Heavy Duty Direct Pole Mount


Please call 800-839-4734 to ensure these options are right for your business.

Photocontrol Photocell - sensor detects sunrise and sunset and automatically activates the light accordingly. Select 120V or 208-277V photocontrol.

Glare Shield - select Half or Full shield.

Wireguard - offers further protection against vandalism.

Polycarbonate Guard - a clear protective lens.

Baffle - for a very narrow lighting spread. Choose Full or Half.
